ARRI ALEXA 35

A new era in digital cinematography

Κατηγορίες: , , Ετικέτες: , ,
Περιγραφή

Η τελευταία προσθήκη της ARRI στις κάμερες με Super35 σένσορα και με ανάλυση 4.6Κ

Κύρια Χαρκτηριστικά:

  • 4.6K Super35 Sensor
  • 17 stops δυναμική περιοχή
  • Μεγαλύτερη ευαισθησία σένσορα ( έως 6400ISO)
  • Arri Textures



Τεχνικά Χαρακτηριστικά
Sensor Type

Super 35 format ARRI ALEV 4 CMOS sensor with Bayer pattern color filter array

Sensor Maximum Number of Photosites and Size

4608 x 3164
27.99 x 19.22 mm / 1.102x 0.757"
Ø 33.96 mm / 1.337"

Sensor Frame Rates

0.75 – 120 fps

Weight

2.9 kg / 6.4 lbs (camera body with three antennas and LPL Mount (LBUS))

Recording File Container Size (pixel)

4.6K 3:2 Open Gate: 4.6K (4608 x 3164)
4.6K 16:9: 4.6K (4608 x 2592), 4K (4096 x 2304)
4K 16:9: 4K (4096 x 2304), UHD (3840 x 2160), 2K (2048 x 1152), HD (1920 x 1080)
4K 2:1: 4K (4096 x 2048)
3.8K 16:9: UHD (3840 x 2160)
3.3K 6:5: 3.3K (3328 x 2790), 4K (4096 x 1716)
3K 1:1: 3K (3072 x 3072), 3.8K (3840 x 1920)
2.7K 8:9: UHD (3840 x 2160)
2K 16:9 S16: 2K (2048 x 1152)

Recording Formats

MXF/ARRIRAW
MXF/Apple ProRes 4444 XQ
MXF/Apple ProRes 4444
MXF/Apple ProRes 422 HQ

Recording Frame Rates

ARRIRAW 4.6K 3:2 Open Gate: 35 / 75 fps
ARRIRAW 4.6K 16:9 – 4.6K: 45 / 75 fps
ARRIRAW 4K 16:9 – 4K: 55 / 120 fps
ARRIRAW 4K 2:1 – 4K: 65 / 120 fps
ARRIRAW 3.8K 16:9 – UHD: 65 / 120 fps
ARRIRAW 3.3K 6:5 – 3.3K: 55 / 100 fps
ARRIRAW 3K 1:1 – 3K: 55 / 100 fps
Apple ProRes 4.6K 3:2 Open Gate: 60 / 60 fps
Apple ProRes 4.6K 16:9 – 4K: 75 / 75 fps
Apple ProRes 4K 16:9 – 4K: 100 / 100 fps
Apple ProRes 4K 16:9 – UHD: 120 / 120 fps
Apple ProRes 4K 16:9 – 2K: 120 / 120 fps
Apple ProRes 4K 16:9 – HD: 120 / 120 fps
Apple ProRes 4K 2:1 – 4K: 120 / 120 fps
Apple ProRes 3.3K 6:5 – 3.3K: 75 / 75 fps
Apple ProRes 3.3K 6:5 – 4K 2.39:1 Ana. 2x: 90 / 90 fps
Apple ProRes 3K 1:1 – 3K: 90 / 90 fps
Apple ProRes 3K 1:1 – 3.8K 2:1 Ana. 2x: 100 / 100 fps
Apple ProRes 2.7K 8:9 – UHD 16:9 Ana. 2x: 100 / 100fps
Apple ProRes 2K 16:9 S16 – 2K: 120 / 120 fps
(Compact Drive 1TB / 2TB)

Measurements (HxWxL)

147 x 152.5 x 203 mm

Image Outputs

2x VF custom CoaXPress connectors for MVF-2 viewfinder
2x 12G SDI (BNC): 422 1.5G HD, 422 3G HD, 444 3G HD, 422 6G UHD, 422 12G UHD, 444 12G UHD

Lens Squeeze Factors

1.00, 1.25, 1.30, 1.33, 1.50, 1.65, 1.80, 1.85, 2.00
