Name: ARRI ALEXA Mini LF
SKU: 11187
Availability: InStock

ARRI ALEXA Mini LF

Large Format, Small Camera

Sensor Type	Super 35 format ARRI ALEV 4 CMOS sensor with Bayer pattern color filter array
Sensor Maximum Number of Photosites and Size	4448 x 3096 36.70 x 25.54 mm / 1.444 x 1.005" ⌀ 44.71 mm / 1.760"
Sensor Frame Rates	0.75 – 100 fps
Weight	∼2.6 kg / ∼5.7 lbs (camera body with LPL lens mount) 800 g (MVF-2)
Recording File Container Size (pixel)	4.5K LF 3:2 Open Gate ARRIRAW: 4448 x 3096 4.5K LF 3:2 Open Gate Apple ProRes: 4480 x 3096 4.5K LF 2.39:1 ARRIRAW: 4448 x 1856 4.5K LF 2.39:1 Apple ProRes: 4480 x 1856 4.3K LF 16:9: 3840 x 2160, 1920 x 1080 3.8K LF 16:9: 3840 x 2160, 2048 x 1152, 1920 x 1080 2.8K LF 1:1 ARRIRAW: 2880 x 2880 2.8K LF 1:1 Apple ProRes: 3072 x 3024 3.4K S35 3:2: 3424 x 2202 3.2K S35 16:9: 3200 x 1800 2.8K S35 4:3: 2880 x 2160 2.8K S35 16:9: 1920 x 1080
Recording Formats	MXF/ARRIRAW MXF/Apple ProRes 4444 XQ MXF/Apple ProRes 4444 MXF/Apple ProRes 422 HQ
Recording Frame Rates	4.5K LF 3:2 Open Gate: 0.75 – 40 fps 4.5K LF 2.39:1: 0.75 – 60 fps 4.3K LF 16:9: 0.75 – 48 fps 3.8K LF 16:9: 0.75 – 90 fps 2.8K LF 1:1: 0.75 – 60 fps 3.4K S35 3:2: 0.75 – 60 fps 3.2K S35 16:9: 0.75 – 75 fps 2.8K S35 4:3: 0.75 – 75 fps 2.8K S35 16:9: 0.75 – 100 fps
Measurements (HxWxL)	140 x 143 x 188 mm / 5.5 x 5.6 x 7.4" (camera body with LPL lens mount)
Image Outputs	1x proprietary signal output for MVF-2 viewfinder on VF CoaXPress connector (video, audio, power, control signals) SDI 1: -HD only, Processed or Clean, with or without a look file applied -1.5G 422 HD (SMPTE ST292-1, up to 30 fps, progessive (p) or progressive segmented frame (psf)) -3G 422 HD (SMPTE ST425-1, up to 60 fps, p) -3G 444 HD (SMPTE ST425-3, up to 30 fps, p) SDI 2: -HD or UHD, Clean only, with or without a look file applied, or SDI 1 clone -1.5G 422 HD (SMPTE ST292-1, up to 30 fps, p or psf) -3G 422 HD (SMPTE ST425-1, up to 60 fps, p) -3G 444 HD (SMPTE ST425-3, up to 30 fps, p) -6G 422 UHD (SMPTE ST2081-10, up to 30 fps, p) “Clean” is an image without surround view or overlays (status, false color, zebra, framelines, etc.) “Processed” is an image with surround view or overlays.
Lens Squeeze Factors	1.00, 1.25, 1.30, 1.50, 1.65, 1.80, 2.00

Click to enlarge

Compare

Categories: Cinema, Cameras, Featured Tags: Alexa Mini LF, 4.6k, full frame

Description
Specifications

Description

Versatile and adaptable due to its compact size, low weight, and multiple recording formats, the Mini LF offers the best overall image quality for large format and an exciting new REVEAL Color Science post workflow.

Distinct and cinematic large-format aesthetic
Creative and practical advantages over smaller formats
Highest dynamic range of any large-format camera

Specifications

Sensor Type	Super 35 format ARRI ALEV 4 CMOS sensor with Bayer pattern color filter array
Sensor Maximum Number of Photosites and Size	4448 x 3096 36.70 x 25.54 mm / 1.444 x 1.005" ⌀ 44.71 mm / 1.760"
Sensor Frame Rates	0.75 – 100 fps
Weight	∼2.6 kg / ∼5.7 lbs (camera body with LPL lens mount) 800 g (MVF-2)
Recording File Container Size (pixel)	4.5K LF 3:2 Open Gate ARRIRAW: 4448 x 3096 4.5K LF 3:2 Open Gate Apple ProRes: 4480 x 3096 4.5K LF 2.39:1 ARRIRAW: 4448 x 1856 4.5K LF 2.39:1 Apple ProRes: 4480 x 1856 4.3K LF 16:9: 3840 x 2160, 1920 x 1080 3.8K LF 16:9: 3840 x 2160, 2048 x 1152, 1920 x 1080 2.8K LF 1:1 ARRIRAW: 2880 x 2880 2.8K LF 1:1 Apple ProRes: 3072 x 3024 3.4K S35 3:2: 3424 x 2202 3.2K S35 16:9: 3200 x 1800 2.8K S35 4:3: 2880 x 2160 2.8K S35 16:9: 1920 x 1080
Recording Formats	MXF/ARRIRAW MXF/Apple ProRes 4444 XQ MXF/Apple ProRes 4444 MXF/Apple ProRes 422 HQ
Recording Frame Rates	4.5K LF 3:2 Open Gate: 0.75 – 40 fps 4.5K LF 2.39:1: 0.75 – 60 fps 4.3K LF 16:9: 0.75 – 48 fps 3.8K LF 16:9: 0.75 – 90 fps 2.8K LF 1:1: 0.75 – 60 fps 3.4K S35 3:2: 0.75 – 60 fps 3.2K S35 16:9: 0.75 – 75 fps 2.8K S35 4:3: 0.75 – 75 fps 2.8K S35 16:9: 0.75 – 100 fps
Measurements (HxWxL)	140 x 143 x 188 mm / 5.5 x 5.6 x 7.4" (camera body with LPL lens mount)
Image Outputs	1x proprietary signal output for MVF-2 viewfinder on VF CoaXPress connector (video, audio, power, control signals) SDI 1: -HD only, Processed or Clean, with or without a look file applied -1.5G 422 HD (SMPTE ST292-1, up to 30 fps, progessive (p) or progressive segmented frame (psf)) -3G 422 HD (SMPTE ST425-1, up to 60 fps, p) -3G 444 HD (SMPTE ST425-3, up to 30 fps, p) SDI 2: -HD or UHD, Clean only, with or without a look file applied, or SDI 1 clone -1.5G 422 HD (SMPTE ST292-1, up to 30 fps, p or psf) -3G 422 HD (SMPTE ST425-1, up to 60 fps, p) -3G 444 HD (SMPTE ST425-3, up to 30 fps, p) -6G 422 UHD (SMPTE ST2081-10, up to 30 fps, p) “Clean” is an image without surround view or overlays (status, false color, zebra, framelines, etc.) “Processed” is an image with surround view or overlays.
Lens Squeeze Factors	1.00, 1.25, 1.30, 1.50, 1.65, 1.80, 2.00
